| General Information |
|---|
| Host Name | mx10-11-161-221 |
| IP Address | 172.120.214.22 |
| Time Stamp | 2025-04-27 21:40:31.259 |
| Sequence Number | 316843 [ Info ] |
| Frame Number | 8480637 |
| Image Type | Event |
| Image Path | 10_11_161_221/316/843/E00000.jpg |
| File Size | 162276 bytes (158 KB) |
| System |
|---|
| Model | Q24M-Secure |
| Factory IP Adress | 10.11.161.221 |
| Hardware | T2r3.1, 806 MHz, 256 MBytes RAM |
| Software | MX-V4.1.6.27 |
| Time Server IP(s) | time.windows.com |
| Current Uptime | 6 days 17:48:13 |
| Event & Action |
|---|
| Event Counter | 334281 |
| Triggered Events | SB_Arm_Record_VM (IMA) |
| Actions | REC FS |
| Event Status | running |
| Last Event | 2025-04-27 21:40:30 |
| Recording Mode | Event Streaming |
| Recording Time | before 2 sec, after 10 sec, stop 10 sec |
| Recording Speed | 4.00 fps |
| Event Recording Speed | max fps |
| Alarm Counter | 253263 |
| Visual Alarm (VA) | hidden |
| Event History |
|---|
| UC (SIG) | 316/683/E00000.jpg [ show info ] |
| SB_Arm_Record_UC (SIG) | 316/683/E00000.jpg [ show info ] |
| SB_Arm_Record_VM (IMA) | 316/838/E00000.jpg [ show info ] |
| SB_Arm_Record_AS (IMA) | 316/842/E00000.jpg [ show info ] |
| Sensors |
|---|
| Video Motion (VM) Window # | 5 |
| Illumination (IL) | 160.6 lux |
| Buttons (BT) | none |
| Internal Temperature (TP) | 28.6°C (83.4°F) |
| Image Setup |
|---|
| Image Codec | MxPEG (16384 KBytes) |
| Image Properties | Right, R=Full Image, 1280x960, 60% JPEG quality, Recording |
| Mounting | Wall |
| Digital Zoom | 1.0x |
| Mirror & Rotation | none |
| Sharpness | 8 |
| Noise Suppress | low |
| Auto Contrast | auto |
| Brightness | 0 |
| Backlight | 8 |
| Night Improve | on (19.9%) |
| Exposure Field | all |
| Exposure Field Weighting | 100% |
| White Balance Weighting | total |
| Average Brightness | 39.8% |
| White Balance Range | 100% |
| Hardware Default (G1 R B G2) | 1024 1024 1024 1024 |
| Color Saturation | 10 |
| Blue Balance | 0 |
| Red Balance | 0 |
| Current Auto Contrast | 0→0, 2→0, 249→255, 255→255 |
| Used Auto Contrast | 2→0, 250→255, 255→255 |
| Current Color (G1 R B G2) | 97.4 103.2 93.4 95.9 |
| White Balance Color (G1 R B G2) | 135.1 138.3 137.2 137.0 |
| Current Correction (G1 R B G2) | 1084 1059 1067 1069 |
| Black Level (G1 R B G2) | 8.9 7.8 7.2 9.2 |
| Used Color Correction (G1 R B G2) | 1088 1059 1074 1071 |
| Hardware Gain (G1 R B G2) | 4608 4864 7936 4608 |
| Exposure Time | 20 ms (prog=+0, min=0.16 ms, max=160 ms) |
| Exposure Control Flags | exposure frozen
hold |
| Reference Illumination | 1621.4 lux (64.2 dB) |
| Control Duration | 0 images |
| Stable Counter | 23000 images |
| Gain Change (G1 R B G2) | 0.00 0.00 0.00 0.00 |
| Frame Rate | 4 fps |
| Power Supply Frequency | 50 Hz |
